Description
FEATURES
 |
Two gears
One gear forward and one reverse, for easy operation.
|
 |
Dual-rotating tines
The tines rotate either forward or reverse. Use forward-rotating mode for top soil cultivation and counter-rotating mode for deep soil tilling.
|
 |
Driven wheels with chevron tyres
Large wheels with heavy treads for optimised grip.
|
 |
Counterweight
For safe and sturdy operation. The counterweight increases weight on the wheels and improves balance.
|
-
Adjustable handlebar
Adjustable handlebar for customised comfort.
-
Easy-access controls
Controls are easily accessible and designed for optimum user comfort.
-
Engine Engine manufacturer Subaru Engine type OHC Engine name EX17 Cylinder displacement 10.31 cu.inch / 169 cm³ Net power at preset rpm 3.14 kW @ 3600 rpm Air filter type Cartridge with pre filter Fuel tank volume 0.9 gal. / 3.4 litre Rotational speed 3600 rpm Rotational speed (min/max) 3500-3700 rpm Transmission Transmission type Chain/Gear Transmission steps forward 1 Transmission steps reverse 1 Capacity Cultivator type Rear-tine Number of tines 12 Tine diameter 13 inch / 330.2 mm Working width 17 inch / 43.18 cm Working depth 6.5 " / 16.51 cm Depth adjustment steps 7 Equipment Vertically adjustable handlebar Yes Transport wheel/s 2 Drag bar Yes Plant guards Yes Driven wheels Yes Chevron tyres No Dimensions Tyre size 330 mm / 13 " Weight 197 lbs / 89.36 kg
